General Purpose Single Phase Motors

Amps: 0.25Bearings: BallCapacitor: 1MFD/250VAC (Included)CFM: 50Enclosure Type: OpenFrame: 3.3"HP: 1/125Motor Diameter: 3.3"Motor Shell Length: 5.1...

Amps: 0.7Bearings: SleeveEnclosure Type: OAO (Open Air Over)Frame: 3.3"HP: 1/70Hz: 60Motor Diameter: 3.3"Motor Shell Length: 2-1/8"Mounting: StudNu...

Amps: 2.4Bearings: SleeveEnclosure Type: OAO (Open Air Over)Frame: 4.4"HP: 1/15Hz: 60Motor Diameter: 4.4"Motor Shell Length: 3"Mounting: StudNumber...

Amps: 13.4/6.8-6.7Bearings: BallDuty Cycle: ContinuousEfficiency: 0.72Enclosure Material: SteelEnclosure Type: TEFC (Totally Enclosed Fan Cooled)Fr...

Product Type: Capacitor Start, Capacitor Run HP: 3/4 RPM: 1725 Volts: 115/230 Amps: 5.2/10.4 Hz: 60 Phase: 1 Frame: 56 Enclosure Type: TEFC...

Amps: 1.3Bearings: SleeveEnclosure Type: OAO (Open Air Over)Frame: 3.3"HP: 1/30Hz: 60Motor Diameter: 3.3"Motor Shell Length: 2-3/4"Mounting: StudNu...

Amps: 1.3Bearings: SleeveEnclosure Type: OAO (Open Air Over)Frame: 3.3"HP: 1/30Hz: 60Motor Diameter: 3.3"Motor Shell Length: 2-5/8"Mounting Orienta...

Amps: 4.1/3.2/2.5Bearings: SleeveCapacitor: 5MFD/370VACEnclosure Type: OAO (Open Air Over)Frame: 5"HP: 1/4HP: 1/5HP: 1/6Hz: 60Motor Diameter: 5"Mot...

Amps: 1.8Bearings: SleeveEnclosure Type: OAO (Open Air Over)Frame: 3.3"HP: 1/20Hz: 60Motor Diameter: 3.3"Motor Shell Length: 2-3/4"Mounting: StudNu...

Amps: 1.1/.8/.6Bearings: SleeveCross Reference: Portable Humidifier MotorsEnclosure Type: OAO (Open Air Over)Frame: 3.3"HP: 1/50HP: 1/65HP: 1/80Mot...

Amps: 1.1Bearings: SleeveCapacitor: 5MFD/370VACEnclosure Type: OpenFrame: 42HP: 1/12Motor Diameter: 5"Motor Shell Length: 3"Number of Speeds: 1Phas...

Amps: 1.7Bearings: SleeveCapacitor: 7.5MFD/370VACEnclosure Type: OpenFrame: 3.3"HP: 1/7Motor Diameter: 3.3"Motor Shell Length: 4-3/4"Mounting: Base...

Amps: 4/2.5Bearings: SleeveEnclosure Type: OAO (Open Air Over)Frame: 4.4"HP: 1/20HP: 1/8Hz: 60Motor Diameter: 4.4"Motor Shell Length: 3-5/8"Mountin...

Amps: 1.1/0.6Bearings: SleeveCapacitor: IncludedEnclosure Type: OAO (Open Air Over)Frame: 3.3"HP: 1/12Hz: 60Motor Diameter: 3.3"Motor Shell Length:...

Amps: 4.4/2.2Bearings: BallDuty Cycle: ContinuousEfficiency: 0.724Enclosure Material: SteelEnclosure Type: ODP (Open Dripproof)Frame: 56CHP: 1/2Hz:...

Product Type: Capacitor StartHP: 1RPM: 3450Volts: 115/208-230Amps: 6.1/6/12Hz: 60Phase: 1Frame: 56Enclosure Type: TEFC (Totally Enclosed Fan Cooled...

C688ES replaces cat# C688 Product Type: Capacitor Start, Capacitor Run HP: 1-1/2 RPM: 1725 Volts: 115/208-230 Amps: 15.0/7.8-7.5 Hz: 60...

Amps: 4.6/2.3Bearings: BallDuty Cycle: ContinuousEnclosure Material: Rolled SteelEnclosure Type: ODP (Open Dripproof)Frame: 56HP: 1/2Hz: 60Insulati...

Product Type: Capacitor StartHP: 1/3RPM: 1725Volts: 115/208-230Amps: 6.4/3.2Hz: 60Phase: 1Frame: 56CEnclosure Type: TEFC (Totally Enclosed Fan Cool...

Amps: 23/11.5Bearings: BallDuty Cycle: ContinuousEfficiency: 74.0%Enclosure Material: SteelEnclosure Type: TEFC (Totally Enclosed Fan Cooled)Frame:...

Amps: 8.7-7.9Bearings: BallDuty Cycle: ContinuousEfficiency: 82.5%Enclosure Material: SteelEnclosure Type: TEFC (Totally Enclosed Fan Cooled)Frame:...

Amps: 3.1Bearings: SleeveCross Reference: 7108-2101Used in Jenn Air unitsEnclosure Type: OAO (Open Air Over)Frame: 4.4"HP: 1/12Motor Diameter: 4.4"...

Amps: 4Bearings: SleeveEnclosure Type: OAO (Open Air Over)Frame: 4.4"HP: 1/12Hz: 60Motor Diameter: 4.4"Motor Shell Length: 2-3/4"Mounting: StudNote...
