Marathon PSC (Permanent Split Capacitor) 5-5/8" Diameter General Purpose Motor - P192
Sold out
$193.76
Out of stock in our warehouses. Please call us for factory stock.
Catalog#: P192
Manufacturer: Marathon
Returns & Warranties
- Product Type: PSC (Permanent Split Capacitor)
- HP: 0.6
- RPM: 1075
- Volts: 200-230/460
- Amps: 4.6-4.0/2.0 A
- Hz: 60
- Phase: 1
- Frame: 48Z
- Enclosure Type: ODP (Open Dripproof)
- Enclosure Material: Steel
- Mounting Type: Band
- Mounting Orientation: Vertical Shaft Up
- Motor Diameter: 5-5/8"
- Shaft Diameter: 5/8"
- Shaft Length: 4.23"
- Motor Shell Length: 6.22"
- Overall Length: 12.65"
- Rotation: Reversible
- Number of Speeds: 1
- Service Factor: 1
- Bearings: Ball
- Efficiency: 62.7%
- Thermal Protection: Automatic
- Maximum Ambient Temperature: 60° C
- Insulation Class: B
- Duty Cycle: Continuous
- Capacitor: Not Included, Use Existing Capacitor in Application
- Manufacturer Model #: 5KCP36PNB523S
- Ship Weight: 19 lbs.
